MathJax Math

Display mathematical equations and formulas using LaTeX-style syntax with MathJax.

A table mapping LaTeX source to rendered output — \(x^2\), \(\sqrt{x}\), \(\frac{a}{b}\), and \(\sum_{i=1}^n x_i\) each typeset as real math by MathJax

Quick Start

Step 1: Enable MathJax

Add mathjax: true to your page's front matter:

---
title: "My Math Page"
mathjax: true
---

Step 2: Write Equations

Inline math with single dollar signs:

The Pythagorean theorem states that $a^2 + b^2 = c^2$.

Display math with double dollar signs:

$$
E = mc^2
$$

Configuration

Theme Integration

The theme includes MathJax support. The include file loads MathJax conditionally:

{% raw %}{% if page.mathjax %}
<!-- MathJax 3 configuration — must appear before the script tag.
     Enables $...$ inline math (off by default in MathJax 3). -->
<script>
window.MathJax = {
  tex: {
    inlineMath: [['$', '$'], ['\\(', '\\)']],
    displayMath: [['$$', '$$'], ['\\[', '\\]']],
    processEscapes: true
  }
};
</script>
<script id="MathJax-script" async
  src="{{ '/assets/vendor/mathjax/es5/tex-mml-chtml.js' | relative_url }}"></script>
{% endif %}{% endraw %}

Syntax Examples

Inline Math

Use single dollar signs or \( \) delimiters:

Markdown Result
$x^2$ \(x^2\)
$\sqrt{x}$ \(\sqrt{x}\)
$\frac{a}{b}$ \(\frac{a}{b}\)
$\sum_{i=1}^n x_i$ \(\sum_{i=1}^n x_i\)

Display Math

Use double dollar signs or \[ \] delimiters for centered equations:

$$
\int_0^\infty e^{-x^2} dx = \frac{\sqrt{\pi}}{2}
$$
\[ \int_0^\infty e^{-x^2} dx = \frac{\sqrt{\pi}}{2} \]

Common Formulas

Quadratic Formula:

$$
x = \frac{-b \pm \sqrt{b^2 - 4ac}}{2a}
$$
\[ x = \frac{-b \pm \sqrt{b^2 - 4ac}}{2a} \]

Matrix:

$$
A = \begin{pmatrix}
a & b \\
c & d
\end{pmatrix}
$$
\[ A = \begin{pmatrix} a & b \\ c & d \end{pmatrix} \]

LaTeX Reference

Greek Letters

Code Symbol Code Symbol
\alpha \(\alpha\) \beta \(\beta\)
\gamma \(\gamma\) \delta \(\delta\)
\pi \(\pi\) \sigma \(\sigma\)
\omega \(\omega\) \theta \(\theta\)

Operators

Code Symbol Description
\sum \(\sum\) Summation
\prod \(\prod\) Product
\int \(\int\) Integral
\partial \(\partial\) Partial derivative
\infty \(\infty\) Infinity
\approx \(\approx\) Approximately
\neq \(\neq\) Not equal
\leq \(\leq\) Less than or equal

Formatting

Code Result Description
x^2 \(x^2\) Superscript
x_i \(x_i\) Subscript
\frac{a}{b} \(\frac{a}{b}\) Fraction
\sqrt{x} \(\sqrt{x}\) Square root
\sqrt[n]{x} \(\sqrt[n]{x}\) nth root
\overline{x} \(\overline{x}\) Overline
\hat{x} \(\hat{x}\) Hat

Troubleshooting

Equations Not Rendering

  1. Check front matter — ensure mathjax: true is set
  2. Check delimiters — use $...$ for inline, $$...$$ for display
  3. Escape special characters — use \\ for backslash in some contexts
  4. Check browser console — look for MathJax loading errors

Dollar Sign Conflicts

If you need literal dollar signs, escape them:

The price is \$5.00, but the formula is $x^2$.

Kramdown Compatibility

Kramdown processes content before MathJax. For complex equations, use the \[ and \] delimiters or wrap in HTML:

<div>
$$
\text{Complex equation here}
$$
</div>

Performance Tips

  1. Only enable when needed — use mathjax: true selectively
  2. Use async loading — the CDN script includes async attribute
  3. Minimize equations — complex equations slow rendering
  4. Consider pre-rendering — for static content, use images

Resources

This guide is part of the Zer0-Mistakes Jekyll Theme documentation.
